Decomposition diagram of outer corner of waterproof column
Installation instructions
Edge trimming of column outer corner: Use drill tail screws to x JH211 on the plane of the column edge, use drill tail screws to x JH211 on the manual
board, use drill tail screws to x JH211 and JH212, fasten JH215 on the groove of JH211, use drill tail screws to x JH175 on the manual board, use JH174
to fasten JH175, and use R50 male angle when the outer corners intersect.
Schematic diagram of waterproof column outer corner trimming
Waterproof internal and external corner decomposition diagram
Installation instructions
Internal and external corner trimming: Use drill tail screws to x JH155 on the plane, use drill tail screws to x JH009 at the intersection of JH155 and
JH157, use drill tail screws to x JH214 on the manual board, use JHOOIA to fasten JH214, use JH213 to fasten JH214, use R100 external corner for
external corner intersection, and R50 internal corner for internal corner intersection.
Schematic diagram of waterproof internal and external corners [Scheme 1]
